Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing

  • Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing
  • Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing
Place of Origin CHINA
Brand Name AIXTON
Certification CE,ROHS,ISO9001,UL
Model Number G652D
Minimum Order Quantity 2000KM
Packaging Details 50.4KM per reel
Delivery Time 30-90
Payment Terms L/C, T/T
Supply Ability 200000KM Per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Highlight

Low Attenuation Bare Fiber Spool

,

FTTH Cable Bare Fiber Spool

,

G652D Bare Fiber Spool
Product Description

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 0

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 1

Optical Fiber
　　　　
ITU-T Classification G.652D
　 　 　 　
Attribute Unit Value Measurement Method
Optical Specifications
Attenuation @ 1310 nm dB/km <0.35 IEC 60793-1-40 *After Hydro-gen aging
Attenuation @ 1383 nm dB/km <0.35
Attenuation @ 1550 nm dB/km <0.21
Attenuation @ 1625 nm dB/km <0.23
Point Discontinuities at 1310 nm and 1550 nm dB <0.05
Zero Dispersion Wavelength nm 1300 to 1324 IEC 60793-1-42
Zero Dispersion Slope ps/nm.km < 0.092
Max Dispersion 1285 nm-1330 nm ps/nm.km <3.5
Dispersion @ 1550 nm ps/nm.km ≤ 18
Dispersion @ 1625 nm ps/nm.km <22
PMD coefficient Individual fiber ps∕√km ≤0.1 IEC 60793-1-4 8
PMD LDV ps/dkm <0.06
Cable cut-oflF Wavelength nm < 1260 IEC 60793-1-44
Mode Field Diameter 1310nm 1550 nm μm 8.6 ±0.4 9.6 ±0.5 IEC 60793-1-45
Difference - Bending Radius
The diagram below llustrates the dilferent bending radius standards for G.652.D, G.657.A1, and G.657.A2. The bending radiusfor G.652.D fiber is 30mm, for G.652A1 fiber is 10mm, and for G.652.A2 fiber optic cable is 7.5mm.





Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 2

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 3

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 4

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 5

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 6

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 7

Factory Direct G652D Single Mode Bare Optical Fiber Spool Low Attenuation Fiber for FTTH Cable Manufacturing 8
