GJYXFCH Outdoor 1 2 Core Fiber Optic Drop Cable G652D G657A1 G657A2 LSZH
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certification | ROHS,Anatel | Item Name | GJYXCH Drop Cable |
|---|---|---|---|
| Core Numbers | 6cores | Mode Type | Single Mode |
| Self-Supporting Strength Member | 3 Steel Wire | Applications | Outdoor Ftth Cabling |
| Sample Status | In Stock | ||
| High Light | LSZH Fiber Optic Drop Cable,FTTH Fiber Optic Drop Cable,Outdoor FTTH Drop Cable |
||
Product Description
Single Mode FTTH Drop Cable G657A1 G652D Zero Halogen Flame Retardant Sheath
GJYXFCH outdoor 1 core and 2 core fibra optica G652D G657A1 G657A2 LSZH fiber optic drop cable
Self-supporting access network uses the indoor outdoor optical cable with a butterfly shape that is to place the optical communication unit in the center, two parallel metallic strength member are placed on both sides , and added single metallic strength member on the outside.Finally it is completed with a black or colored Lsoh Low Smoke Zero Halogen(LSZH) out sheath.
Feature:
1.Soft and bendable, easy to deploy and maintenance.
2.Smaller diameter, Light weight, and high practicability.
3.Fiber reinforced plastic as the strength member ensures excellent anti-electromagnetic performance.
4.Environmental protection- Low smoke, zero halogen and flame retardant sheath.
Applications:
1. Used in access network or as access cable from outdoor to indoor in customer premises network;
2. Used as access building cable in premises distribution system, especially used in indoor or outdoor
Structure
|
Structure |
Unit |
Parameter |
|
|
Fiber count |
Fibers |
2 |
|
|
Diameter |
mm |
5.0*2.0 |
|
|
Weight |
Kg/km |
Approx.21 |
|
|
Sheath color |
|
Black |
|
|
Sheath material |
|
LSZH |
|
|
O.D of steel wire |
mm |
1.0±0.05mm |
|
|
Strength member |
mm |
0.5mm FRP |
|
|
Tensile strength |
N |
1500 |
|
|
Crush Resistance |
N |
2200 |
|
|
Bending Radius |
Dynamic |
|
30×Cable Diameter |
|
Static |
|
15×Cable Diameter |
|
|
Operating Temperature |
℃ |
-40 --- +70 |
|
Test Datasheet
|
Category |
Description |
Specifications |
|
|
G.657A1 |
|||
|
Optical Specifications |
Attenuation |
@1310-1625nm |
≤0.36dB/km |
|
@1383±3nm |
≤0.36dB/km |
||
|
@1550nm |
≤0.22dB/km |
||
|
Attenuation discontinuity |
≤0.05 dB |
||
|
Attenuation vs. Wavelength |
@1285~1330nm |
≤0.05 dB/km |
|
|
@1525~1575nm |
≤0.05 dB/km |
||
|
Zero Dispersion Wavelength |
1300~1324nm |
||
|
Zero Dispersion Slope |
≤0.092ps/(nm2.km) |
||
|
Dispersion |
@1310nm |
≤3.5 ps/nm.km |
|
|
@1550nm |
≤18 ps/nm.km |
||
|
Polarization Mode Dispersion(PMD) |
≤0.2ps/km1/2 |
||
|
Cable Cutoff Wavelength(λcc) |
≤1260nm |
||
|
Effective Group Index of Refraction |
@1310nm |
1.4675 |
|
|
@1550nm |
1.4681 |
||
|
Macro bend loss (30mm radius ,100turns) 1625nm |
≤0.1 dB |
||
|
Geometric Specifications |
Mode Field Diameter |
@1310nm |
9.2±0.6μm |
|
@1550nm |
10.4±0.8μm |
||
|
Cladding Diameter |
125±1μm |
||
|
Cladding Non-Circularity |
≤1.0% |
||
|
Coating Diameter |
245±7μm |
||
|
Coating/Cladding Concentricity Error |
≤8μm |
||
|
Core/Cladding Concentricity Error |
≤0.8μm |
||
|
Mechanical Specifications |
Proof Test level |
≥1.0% |
|
|
Fiber Curl Radius |
≥4.0m |
||
|
Peak Coating Strip Force |
1.3~8.9N |
||
FAQ
Q1: What are the advantages of your price?
A1: We have our own factory, professioanl machinery equipment . We can meet the
price advantage of products with the same quality parameters, and we promise to
achieve a price of 1%-10% lower than that of our peers.
Q2: What is your quality advantage?
A2: We strictly according to the ISO9001 quality management system, insisting
"Enough Cores, Enough Meters, High Quality, High Performance". Providing
our customers with higher quality products and services.
Q3. Do you support customized brands?
A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts
to make the logo free for bulk orders.
Q4: What are the benefits of working with you?
A4: New customers can enjoy AIXTON’s stock and annual year-end dividends, and
support long-term cooperative customers to upgrade to global agents and enjoy more
discounted prices.fibra óptic
